Jib Crane Types
The trolley hoist on a horizontal load-bearing boom are key features on Jib cranes. The boom is secured to a vertical mast that measures up to 20 feet long. Jib cranes can move loads between any areas within the boom's arc of rotation. Light duty models are used inside factories and warehouses for loads weighing up to 5 tons. The website BestJibCranes.com features the major jib crane models as being either free-standing, wall-mounted or mast mounted.
Free Standing
The free-standing jib crane units do not need any support from the building structure and are able to stand by themselves. The horizontal boom in this case is attached to a pivoting vertical column which is firmly anchored to the floor of the building. This type of jib crane is able to rotate a full 360 degrees and requires a foundation made of either concrete or steel.
Mast-Type
The mast-type jib cranes feature a vertical column that is supported by pivot points at the top and the bottom which are attached to the building floor and the overhead steel structure. These jib-cranes offer 360 degrees of rotation with the benefit of not needing the massive foundation needed for free-standing units.
Wall Mounted
The wall-mounted jib cranes provide a horizontal boom which is connected to the wall of a building rather than the normal vertical column. These equipments offer up to 200 degrees of rotation and are ideal in places where the full 360 degree rotation is not required.
Depending on how the boom is supported, there are two model varieties. One kind utilizes a tie rod from above the boom that is attached to the wall. The other type supports the boom from below by utilizing a cantilever brace that is connected to the wall as well.
